Maine 30" Electric Cooktop with Bridge Element
Black Kanger® Vitroceramic Glass Cooktop
Key Features:
- Vitroceramic Surface: Optimal heat conductivity
- Power Options: Select from 9 power levels
- Other Features: Timer (up to 99 minutes), child lock
- cETL-Certified: Meets strict electrical safety standards
- Warranty: 2 years for parts and labor
Elements/Burners:
- Front-Left Element: 1,600W
- Front-Right Element: 1,200W
- Center Element: 3,600W (1,200W × 3)
- Rear-Left Element: 1,600W
- Bridge Zone: 400W
Specifications:
- Model: VCE-MAINE-30SS
- Dimensions (W×H×D): 30" × 1.81" × 21"
- Cut-Out Dimensions (W×D): 28.81" × 19.44"
- Power Type: Electric
Pairs well with
Maine 30" Electric Cooktop with Bridge Element
If you have any questions about technical details, dimensions, or shipping, feel free to reach out to us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
• Free Shipping: All range hood orders over $250 USD qualify for free shipping.
• Standard Shipping: Orders typically ship via UPS Standard.
• Other Categories: Shipping fees for non-range hood products are calculated at checkout.
• Expedited Shipping: Need it sooner? Expedited shipping is available at an additional cost.
• Accessories: A flat shipping fee of $16.99 USD applies to all accessories. -
Customer Support
If you have any questions or concerns, feel free to reach us directly at 905-886-5858 or service@vesta.kitchen.
-
Troubleshooting
No Electricity After Installation
• Confirm the range hood wiring is correct.
• Check the circuit’s power supply and make sure the fuse is intact.
Vibration During Operation
• Confirm the range hood wiring is correct.
• Check the circuit’s power supply and make sure the fuse is intact.
Weak Suction
• Ensure the exhaust duct is at least 4 inches in diameter, under 10 feet in length, and has fewer than 3 turns. If any of these conditions are not met, it’s likely not a range hood issue.
• Test suction by running the hood without the duct. If it works normally, the duct setup is the problem; otherwise, contact the manufacturer.
• Check that the outlet flap is fully open. If there’s an exterior wind shield, consider removing its flap to prevent airflow obstruction.
Blower Doesn’t Rotate (Light is On)
• This may indicate a circuit board failure. Please contact the manufacturer.
Fan Wheel Stuck or Rattling
• The blower might be touching nearby wires; clean around it to remove any obstruction.
• If the fan is jammed or damaged from shipping, contact the manufacturer. -
Contact Us
We’re here for you Monday–Friday, 9 a.m.–5 p.m. EST. Call us at 1-866‑808‑3782 or email service@vesta.kitchen.
Specifications
| Model Number | VCE-MAINE-30SS |
|---|---|
| Nominal Width | 30" |
| Dimensions (W×D×H) | 30" × 21" × 1.8" |
| Cut Out Dimensions (W×D) | 28.63" × 19.44" |
| Product Weight | 14.4 kg |
| Color/Finish | Black |
| Electrical Requirements | 120V/60Hz |
|---|
| Power Type | Electric |
|---|---|
| Cooktop plate | Black Polished Glass-Ceramic Cooktop |
| Burners | 4 |
| Right Front | 1,200W |
| Left Front | 1,600W |
| Center Rear | 3,600W(1,200W × 3) |
| Left Rear | 1,600W |
| Bridge Zone Element | 400W |
| Features | 9 Power Stage Setting, 99 Minutes Timer, Child Lock |
| Warranty (Parts & Labor) | 2 Years |
| Certification | CSA |
Instructions
Installation
Cleaning
User Manual
Download our range hood user manual to find everything you need for a smooth installation and optimal performance. The manual covers:
- Installation Steps: Proper setup procedures and essential precautions
- Operating Instructions: How to use the control panel and adjust fan speeds
- Maintenance Tips: Cleaning intervals, filter replacement, and basic troubleshooting
- Safety Guidelines: Important safety measures for daily operation
Be sure to read the manual thoroughly and keep it on hand for reference. If you need further assistance, our customer support team is here to help.
